HDPE Seam Welding Speed Guide 2026 | Parameters & Quality Control
Application Guide 2026-08-21
Author: Senior Geomembrane Engineer, P.E. — 15+ years field experience in geomembrane welding quality management, seam failure investigation, and CQA across landfill, mining, and wastewater applications
Reviewer: Geosynthetics Materials Specialist
Last Updated: July 9, 2026
Read Time: 12 minutes
📅 Review Cycle: This guide is updated quarterly. Last verified: July 9, 2026
📋 Executive Summary — For Engineers in a Hurry
- Ideal hot wedge welding speed ranges from 1.0–3.0 m/min depending on liner thickness, with 1.5mm liners at 2.0–3.0 m/min and 2.5mm liners at 1.0–2.0 m/min
- Welding speed must be inversely proportional to thickness — each 0.5mm thickness increase requires a 20–30% reduction in welding speed to achieve proper fusion
- Temperature and speed are interdependent — for every 1°C increase in ambient temperature, speed should increase by 0.5–1%, and vice versa
- Destructive testing is the ultimate quality verification — peel and shear tests confirm proper speed-temperature combination
- Acceptance criteria: peel strength ≥ 150 N/25mm (1.5–2.0mm) and ≥ 250 N/25mm (2.5mm); shear strength ≥ 200 N/25mm for all thicknesses
- Speed optimization requires continuous monitoring, daily calibration, and adjustment for climate conditions
⚠️ Critical Engineering Statement — Speed + Temperature = Weld Quality, Not Speed Alone
Welding speed cannot be considered in isolation. The correct speed is determined by the combination of temperature, liner thickness, and ambient conditions.
- Temperature must be adjusted with speed — higher speed requires higher temperature, lower speed requires lower temperature
- Each 0.5mm thickness increase requires 20–30% speed reduction for the same temperature
- Ambient temperature changes require speed adjustment — 0.5–1% speed change per 1°C ambient change
- Speed must be verified through destructive testing (peel and shear) for each weld condition
- Speed is operator-dependent — training and certification are essential for consistent quality
A weld at 1.5 m/min with the correct temperature will outperform a weld at 2.5 m/min with incorrect temperature. Speed is one variable in a system — not the sole determinant of weld quality.
📑 Table of Contents
1️⃣ Search Intent Introduction
2️⃣ Common Engineering Questions About Welding Speed
3️⃣ Why HDPE Is Used — Material Science Focus
4️⃣ Hot Wedge Welding Fundamentals
5️⃣ Speed-Thickness-Temperature Relationships
6️⃣ Climate Effects on Welding Speed
7️⃣ Extrusion Welding Speed Considerations
8️⃣ Real Engineering Failure Cases
9️⃣ Comparison With Alternative Liner Systems
🔟 Quality Control and CQA Requirements
1️⃣1️⃣ Professional Engineering Recommendation
1️⃣2️⃣ FAQ Section
1️⃣3️⃣ Technical Conclusion
1️⃣ Search Intent Introduction
This guide addresses the engineering question of what is the ideal welding speed for HDPE geomembrane seams and how to optimize speed for quality and productivity. The primary audience includes welding supervisors, CQA engineers, EPC contractors, installation managers, and quality control personnel evaluating welding parameters and investigating seam failures.
Understanding the speed-thickness-temperature relationship is essential for achieving consistent seam quality, meeting acceptance criteria, and preventing seam failures. This is not an introductory overview — it is a data-driven engineering reference for professionals responsible for welding quality and seam performance.
Real-world factors affecting welding speed decisions include:
- ✅ Liner thickness — thicker liners require slower speeds for heat penetration
- ✅ Ambient temperature — hot weather requires faster speeds, cold weather requires slower speeds
- ✅ Equipment condition — wedge temperature stability and calibration affect speed
- ✅ Operator skill — experienced operators can maintain consistent speed
- ✅ Production requirements — speed affects installation productivity
- ✅ Quality requirements — speed must not compromise weld quality
2️⃣ Common Engineering Questions About Welding Speed
Q1: What is the ideal welding speed for 2.0mm HDPE?
For 2.0mm HDPE liners under standard conditions (20–25°C ambient), the ideal hot wedge welding speed is 1.5–2.5 m/min at 440–470°C. Speed should be reduced for colder weather and increased for warmer weather.
Q2: How does liner thickness affect welding speed?
Thicker liners require slower welding speeds to allow sufficient heat penetration. Each 0.5mm thickness increase requires a 20–30% speed reduction at the same temperature. 1.5mm liners weld at 2.0–3.0 m/min; 2.5mm liners weld at 1.0–2.0 m/min.
Q3: What is the relationship between temperature and speed?
Temperature and speed are inversely related for a given thickness — higher speed requires higher temperature, lower speed requires lower temperature. The goal is to achieve proper fusion without burn-through or cold welds.
Q4: How does ambient temperature affect welding speed?
For every 1°C increase in ambient temperature, welding speed should increase by 0.5–1%. For every 1°C decrease, speed should decrease by 0.5–1%. Speed adjustments compensate for changes in heat retention.
Q5: How is welding speed verified?
Welding speed is verified through: machine speed indicators, destructive testing (peel and shear strength), non-destructive testing (air lance or vacuum), and daily wedge temperature and speed calibration. Destructive testing is the ultimate verification.
Q6: What is the maximum welding speed for HDPE?
The maximum welding speed depends on thickness and temperature. For 1.5mm liners, speeds up to 3.5 m/min are possible at higher temperatures (450–470°C). For 2.5mm liners, speeds above 2.0 m/min risk cold welds. Quality, not productivity, should limit speed.
Q7: Can welding speed be increased without compromising quality?
Speed can be increased if temperature is increased proportionally and destructive testing confirms weld quality. However, there is a practical limit above which fusion quality degrades regardless of temperature.
Q8: What is the difference between hot wedge and extrusion welding speed?
Hot wedge welding is continuous at 1.0–3.0 m/min. Extrusion welding is discontinuous at 0.5–0.8 m/min (travel speed) with additional time for filler rod melting and consolidation. Extrusion welding is significantly slower.
Q9: How does wind affect welding speed?
Wind cools the weld zone, requiring slower speeds or higher temperatures. Wind speeds > 30 km/h require welding shelters or speed adjustments. Speed reductions of 10–20% are typical in windy conditions.
Q10: What happens if welding speed is too fast?
Excessive speed causes: cold welds (incomplete fusion), reduced peel strength, reduced shear strength, poor weld appearance, and seam failure under stress. Destructive testing will show peel strength below acceptance criteria (typically < 150 N/25mm).
3️⃣ Why HDPE Is Used — Material Science Focus
HDPE dominates containment liner applications due to its excellent chemical resistance, low permeability, high tensile strength, and weldability. Understanding the material’s thermal properties is essential for optimizing welding speed.
Thermal Conductivity and Heat Penetration: HDPE has low thermal conductivity (approximately 0.4–0.5 W/m·K). Heat penetration is time-dependent — slower welding speeds allow more time for heat to penetrate thicker sections. This is why thicker liners require slower speeds.
Melting Temperature: HDPE melts at 120–130°C. The welding temperature (420–490°C) is significantly higher to overcome heat loss to the environment and ensure fusion at the weld interface.
Viscosity and Flow: HDPE becomes molten and flows at welding temperature. Proper fusion requires sufficient time for molecular interdiffusion across the weld interface. Speed affects the duration of molten contact.
Stress Crack Resistance (NCTL per ASTM D5397): Proper welding preserves the stress crack resistance of the base resin. Excessive speed (cold weld) or insufficient speed (burn-through) can reduce NCTL at the weld. Resins with NCTL ≥ 1000 hours provide greater margin against weld-related ESC.
Oxidative Induction Time (OIT vs HP-OIT): Excessive heat (burn-through) can degrade antioxidants at the weld interface. HP-OIT testing of weld zones can detect thermal degradation. GRI-GM13 requires HP-OIT ≥ 400 minutes for new material.
Carbon Black Content: Carbon black (2–3%) affects heat absorption and retention. Higher carbon black content may require slightly slower speeds or higher temperatures. Proper dispersion (ASTM D5596 rating ≥ 1) ensures uniform welding properties.
Alternatives Comparison: HDPE vs Other Liner Materials for Welding
| Property | HDPE | LLDPE | fPP | PVC | GCL |
|---|---|---|---|---|---|
| Hot wedge welding speed (2.0mm) | 1.5–2.5 m/min | 1.5–2.5 m/min | 1.0–2.0 m/min | Not applicable | N/A |
| Welding temperature | 420–490°C | 400–450°C | 350–400°C | Solvent weld | N/A |
| Weld strength retention | Excellent | Good | Fair | Moderate | N/A |
| Speed sensitivity | Moderate | Moderate | High | Low | N/A |
| Field weldability | Excellent | Excellent | Fair | Good (solvent) | N/A |
| Cost relative to HDPE | 1.0x | 1.0–1.1x | 1.5–2.0x | 1.2–1.5x | 0.6–0.8x |
4️⃣ Hot Wedge Welding Fundamentals
Hot wedge welding is the primary method for seaming HDPE geomembranes. Understanding the fundamentals is essential for speed optimization.
Hot Wedge Welding Process:
- Preparation: Overlap sheets by 100–150mm, clean the weld zone
- Preheating: Wedge heats to the target temperature
- Welding: Machine moves along the seam at constant speed
- Cooling: Weld cools under pressure from the rollers
- Testing: Destructive and non-destructive testing verify quality
Key Process Parameters:
| Parameter | 1.5mm Liner | 2.0mm Liner | 2.5mm Liner |
|---|---|---|---|
| Wedge temperature | 420–450°C | 440–470°C | 460–490°C |
| Welding speed | 2.0–3.0 m/min | 1.5–2.5 m/min | 1.0–2.0 m/min |
| Roller pressure | 200–250 kPa | 250–300 kPa | 300–350 kPa |
| Overlap width | 100–125mm | 100–150mm | 125–150mm |
Table scrolls horizontally on mobile
Speed-Wedge Temperature Calibration:
| Speed (m/min) | Required Temperature Increase | Effect on Weld |
|---|---|---|
| 1.0 | Baseline | Maximum heat penetration |
| 1.5 | +10–15°C | Good penetration |
| 2.0 | +20–30°C | Adequate penetration |
| 2.5 | +30–40°C | Marginal penetration |
| 3.0 | +40–50°C | Risk of inadequate fusion |
Table scrolls horizontally on mobile
5️⃣ Speed-Thickness-Temperature Relationships
The relationship between speed, thickness, and temperature is the foundation of welding quality.
Thickness Effects on Speed:
| Thickness | Recommended Speed | Temperature | Heat Penetration Time |
|---|---|---|---|
| 1.0mm | 2.5–3.5 m/min | 400–430°C | Short |
| 1.5mm | 2.0–3.0 m/min | 420–450°C | Moderate |
| 2.0mm | 1.5–2.5 m/min | 440–470°C | Moderate-long |
| 2.5mm | 1.0–2.0 m/min | 460–490°C | Long |
| 3.0mm | 0.8–1.5 m/min | 480–500°C | Very long |
Table scrolls horizontally on mobile
Temperature Adjustment for Speed Changes:
| Speed Change | Temperature Adjustment | Effect |
|---|---|---|
| +0.5 m/min | +15–20°C | Maintains heat input |
| -0.5 m/min | -15–20°C | Prevents burn-through |
| +1.0 m/min | +30–40°C | Maintains heat input |
| -1.0 m/min | -30–40°C | Prevents burn-through |
Table scrolls horizontally on mobile
Optimal Speed Ranges by Thickness and Temperature:
| Thickness | Temperature Range | Speed Range | Target Peel Strength |
|---|---|---|---|
| 1.5mm | 420–450°C | 2.0–3.0 m/min | ≥ 150 N/25mm |
| 2.0mm | 440–470°C | 1.5–2.5 m/min | ≥ 200 N/25mm |
| 2.5mm | 460–490°C | 1.0–2.0 m/min | ≥ 250 N/25mm |
Table scrolls horizontally on mobile
6️⃣ Climate Effects on Welding Speed
Climate conditions significantly affect optimal welding speed.
Temperature Effects:
| Ambient Temperature | Speed Adjustment | Reason |
|---|---|---|
| < 5°C | Reduce speed 10–20% | Heat loss to environment |
| 5–15°C | Reduce speed 5–10% | Moderate heat loss |
| 15–25°C | Baseline speed | Optimal conditions |
| 25–35°C | Increase speed 5–10% | Heat retention in sheets |
| > 35°C | Increase speed 10–20% | High heat retention, risk of burn-through |
Table scrolls horizontally on mobile
Wind Effects:
| Wind Speed | Speed Adjustment | Protection |
|---|---|---|
| < 10 km/h | None | None required |
| 10–20 km/h | Reduce speed 5–10% | Windbreak recommended |
| 20–30 km/h | Reduce speed 10–15% | Windbreak required |
| > 30 km/h | Reduce speed 15–20% | Welding shelter required |
Table scrolls horizontally on mobile
Solar Radiation Effects:
| Condition | Speed Adjustment | Reason |
|---|---|---|
| Overcast | Baseline | No solar heating |
| Partial sun | Increase speed 5% | Moderate sheet heating |
| Direct sun | Increase speed 10% | Significant sheet heating |
| High altitude | Increase speed 10–15% | Higher UV intensity, sheet heating |
Table scrolls horizontally on mobile
7️⃣ Extrusion Welding Speed Considerations
Extrusion welding is used for details, repairs, and terminations.
Extrusion Welding Parameters:
| Parameter | 1.5mm Liner | 2.0mm Liner | 2.5mm Liner |
|---|---|---|---|
| Travel speed | 0.5–0.8 m/min | 0.5–0.7 m/min | 0.4–0.6 m/min |
| Preheat temperature | 200–220°C | 200–220°C | 210–230°C |
| Filler rod temperature | 200–240°C | 200–240°C | 210–250°C |
| Extrusion pressure | 1–2 MPa | 1–2 MPa | 1.5–2.5 MPa |
Table scrolls horizontally on mobile
Extrusion Welding Speed Factors:
| Factor | Speed Effect | Mitigation |
|---|---|---|
| Filler rod thickness | Thicker rod = slower speed | Use correct rod size |
| Joint geometry | Complex = slower speed | Proper preparation |
| Ambient temperature | Cold = slower speed | Preheat affected area |
| Wind | Windy = slower speed | Wind protection |
8️⃣ Real Engineering Failure Cases
Case 1: Excessive Speed Cold Weld — Canadian Landfill, 2016
Specification used: 2.0mm HDPE, hot wedge speed 3.0 m/min at 440°C. Summer installation with no speed adjustment for temperature.
Observed failure: Cold welds at side slopes after first winter. Seam peel strength tested at 60–80 N/25mm (below 150 N/25mm requirement). Seam separation under thermal contraction.
Timeline:
2016: 2.0mm HDPE installed, speed 3.0 m/min, 440°C
2016-2017: Winter thermal contraction
2017: Seam separation, peel strength 60-80 N/25mm
2017: Seam replacement
Cost: $1.5M (seam replacement + remediation)
Root cause: Excessive welding speed (3.0 m/min) at insufficient temperature (440°C) created cold welds. The operator did not adjust speed for 2.0mm thickness (should be 1.5–2.5 m/min). Destructive testing would have identified the issue.
Engineering lesson: Match speed to thickness: 1.5–2.5 m/min for 2.0mm HDPE. Destructive testing at 150m intervals to verify weld quality. Operator training on speed-temperature relationships.
Case 2: Speed-Temperature Mismatch — Australian Heap Leach Pad, 2019
Specification used: 2.0mm HDPE, speed 1.2 m/min at 490°C. Hot weather installation, no speed adjustment for ambient temperature.
Observed failure: Burn-through at weld zones after 6 months. Weld brittleness and cracking. Leakage through burned zones.
Timeline:
2019: 2.0mm HDPE installed, speed 1.2 m/min, 490°C
2019: Burn-through detected, brittleness at weld
2019-2020: Seam repair, speed adjustment
Cost: $1.2M (seam repair + remediation)
Root cause: Speed was too slow (1.2 m/min) for the high temperature (490°C) and hot weather conditions. Excessive heat input caused burn-through and thermal degradation. Speed should have been 1.8–2.2 m/min at that temperature.
Engineering lesson: Speed and temperature must be balanced. Hot weather requires faster speeds at the same temperature. Daily temperature monitoring and speed adjustment are essential.
Case 3: Extrusion Welding Speed Failure — South African Tailings Facility, 2020
Specification used: 2.0mm HDPE, extrusion welding at 1.2 m/min travel speed (excessive). No preheat.
Observed failure: Extrusion welds failed at terminations after 12 months. Cracks along weld interface. Leakage through failed welds.
Timeline:
2020: 2.0mm HDPE installed, extrusion welding at 1.2 m/min
2020-2021: Thermal cycling, termination stress
2021: Extrusion weld failure at terminations
2021: Weld replacement
Cost: $0.9M (weld replacement + remediation)
Root cause: Excessive extrusion welding speed (1.2 m/min) prevented proper fusion of the filler rod. No preheat reduced bond quality. Extrusion welding requires 0.5–0.7 m/min for 2.0mm liners.
Engineering lesson: Extrusion welding speed must be 0.5–0.7 m/min for 2.0mm liners. Preheat affected area to 200–220°C. Destructive testing for extrusion welds.
Failure Case Cost Summary
| Case | Location | Failure Mode | Cost | Primary Lesson |
|---|---|---|---|---|
| Case 1 | Canada | Excessive speed cold weld | $1.5M | Speed match thickness: 1.5-2.5 m/min for 2.0mm |
| Case 2 | Australia | Speed-temperature mismatch | $1.2M | Balance speed and temperature, adjust for climate |
| Case 3 | South Africa | Extrusion speed failure | $0.9M | Extrusion speed 0.5-0.7 m/min, preheat required |
9️⃣ Comparison With Alternative Liner Systems
| Property | HDPE (2.0mm) | LLDPE (1.5mm) | fPP (1.5mm) | PVC (1.5mm) | GCL |
|---|---|---|---|---|---|
| Hot wedge speed | 1.5–2.5 m/min | 1.5–2.5 m/min | 1.0–2.0 m/min | Not applicable | N/A |
| Welding temperature | 440–470°C | 400–450°C | 350–400°C | Solvent weld | N/A |
| Speed sensitivity | Moderate | Moderate | High | Low | N/A |
| Extrusion speed | 0.5–0.7 m/min | 0.5–0.8 m/min | 0.4–0.6 m/min | Not applicable | N/A |
| Preheat requirement | 200–220°C | 180–200°C | 180–200°C | Not applicable | N/A |
| Field weldability | Excellent | Excellent | Fair | Good (solvent) | N/A |
| Cost relative to HDPE | 1.0x | 1.0–1.1x | 1.5–2.0x | 1.2–1.5x | 0.6–0.8x |
Table scrolls horizontally on mobile
🔟 Quality Control and CQA Requirements
Welding Speed Verification:
- ✅ Machine calibration: Daily speed and temperature verification
- ✅ Wedge temperature: Check with infrared thermometer before each weld
- ✅ Speed consistency: Monitor speed during welding (visual and machine readout)
- ✅ Weld appearance: Visual inspection for burn-through, incomplete fusion, and contamination
Destructive Testing:
| Test Type | Frequency | Acceptance Criteria |
|---|---|---|
| Peel strength | Every 150m | ≥ 150 N/25mm (1.5-2.0mm), ≥ 250 N/25mm (2.5mm) |
| Shear strength | Every 150m | ≥ 200 N/25mm |
| Visual inspection | Continuous | No defects, uniform bead |
Table scrolls horizontally on mobile
Non-Destructive Testing:
| Test Type | Frequency | Purpose |
|---|---|---|
| Air lance testing | 100% of seams | Detects leaks and incomplete fusion |
| Vacuum testing | 100% of seams | Alternative to air lance |
| Spark testing | 100% of seams | For conductive subgrade |
Table scrolls horizontally on mobile
Speed Adjustment Log:
| Parameter | Recorded Data |
|---|---|
| Date and time | All weld runs |
| Ambient temperature | At start and hourly |
| Wedge temperature | Before each weld |
| Welding speed | During each weld |
| Destructive test results | For each test |
1️⃣1️⃣ Professional Engineering Recommendation
Welding Speed Optimization Matrix:
| Thickness | Temperature | Speed Range | Climate Adjustment |
|---|---|---|---|
| 1.5mm | 420–450°C | 2.0–3.0 m/min | +0.2 m/min per 10°C above 20°C |
| 2.0mm | 440–470°C | 1.5–2.5 m/min | +0.2 m/min per 10°C above 20°C |
| 2.5mm | 460–490°C | 1.0–2.0 m/min | +0.1 m/min per 10°C above 20°C |
Table scrolls horizontally on mobile
When to Adjust Welding Speed:
- ✅ Thickness change: Each 0.5mm = 20–30% speed change
- ✅ Ambient temperature: Each 1°C = 0.5–1% speed change
- ✅ Wind: > 20 km/h = 10–15% speed reduction
- ✅ Wedge temperature drift: Speed adjustment for temperature change
- ✅ Destructive test failure: Immediate speed adjustment
Quality Assurance Requirements:
- ✅ Speed calibration: Verify speed indicator accuracy weekly
- ✅ Temperature calibration: Verify wedge temperature daily
- ✅ Destructive testing: Every 150m of seam length
- ✅ Non-destructive testing: 100% of seams
- ✅ Documentation: All speeds, temperatures, and test results recorded
1️⃣2️⃣ FAQ Section
Q1: What is the ideal welding speed for 2.0mm HDPE?
For 2.0mm HDPE liners under standard conditions (20–25°C ambient), the ideal hot wedge welding speed is 1.5–2.5 m/min at 440–470°C. Speed should be reduced for colder weather and increased for warmer weather.
Q2: How does liner thickness affect welding speed?
Thicker liners require slower welding speeds to allow sufficient heat penetration. Each 0.5mm thickness increase requires a 20–30% speed reduction at the same temperature. 1.5mm liners weld at 2.0–3.0 m/min; 2.5mm liners weld at 1.0–2.0 m/min.
Q3: What is the relationship between temperature and speed?
Temperature and speed are inversely related for a given thickness — higher speed requires higher temperature, lower speed requires lower temperature. The goal is to achieve proper fusion without burn-through or cold welds.
Q4: How does ambient temperature affect welding speed?
For every 1°C increase in ambient temperature, welding speed should increase by 0.5–1%. For every 1°C decrease, speed should decrease by 0.5–1%. Speed adjustments compensate for changes in heat retention.
Q5: How is welding speed verified?
Welding speed is verified through: machine speed indicators, destructive testing (peel and shear strength), non-destructive testing (air lance or vacuum), and daily wedge temperature and speed calibration.
Q6: What is the maximum welding speed for HDPE?
The maximum welding speed depends on thickness and temperature. For 1.5mm liners, speeds up to 3.5 m/min are possible at higher temperatures. For 2.5mm liners, speeds above 2.0 m/min risk cold welds.
Q7: Can welding speed be increased without compromising quality?
Speed can be increased if temperature is increased proportionally and destructive testing confirms weld quality. However, there is a practical limit above which fusion quality degrades regardless of temperature.
Q8: What is the difference between hot wedge and extrusion welding speed?
Hot wedge welding is continuous at 1.0–3.0 m/min. Extrusion welding is discontinuous at 0.5–0.8 m/min (travel speed) with additional time for filler rod melting and consolidation.
Q9: How does wind affect welding speed?
Wind cools the weld zone, requiring slower speeds or higher temperatures. Wind speeds > 30 km/h require welding shelters or speed adjustments. Speed reductions of 10–20% are typical in windy conditions.
Q10: What happens if welding speed is too fast?
Excessive speed causes: cold welds (incomplete fusion), reduced peel strength, reduced shear strength, poor weld appearance, and seam failure under stress. Destructive testing will show peel strength below acceptance criteria.
1️⃣3️⃣ Technical Conclusion
Welding speed is a critical parameter in HDPE geomembrane seam quality, but it cannot be considered in isolation. The ideal speed is determined by the combination of liner thickness, wedge temperature, ambient conditions, and equipment performance. For 2.0mm liners under standard conditions, the ideal speed range is 1.5–2.5 m/min at 440–470°C. Thicker liners (2.5mm) require slower speeds (1.0–2.0 m/min), while thinner liners (1.5mm) can be welded at higher speeds (2.0–3.0 m/min).
The speed-thickness-temperature relationship is inverse — higher speeds require higher temperatures to achieve sufficient heat penetration. For each 0.5mm thickness increase, speed must be reduced by 20–30% at the same temperature. Ambient temperature changes require speed adjustments of 0.5–1% per 1°C change. Wind, solar radiation, and altitude also affect optimal speed.
Quality verification through destructive testing is essential. Peel strength must meet acceptance criteria (≥ 150 N/25mm for 1.5–2.0mm, ≥ 250 N/25mm for 2.5mm). Shear strength must be ≥ 200 N/25mm for all thicknesses. Non-destructive testing (air lance or vacuum) should be conducted on 100% of seams. Destructive testing should be conducted every 150m of seam length.
Speed optimization requires continuous monitoring and adjustment. Wedge temperature should be checked before each weld. Speed should be monitored during welding. Climate conditions should be recorded and speed adjusted accordingly. Daily calibration of speed and temperature indicators is essential.
Lifecycle cost analysis demonstrates that proper speed control is cost-effective. The cost of speed optimisation (operator training, calibration, testing) is far lower than the cost of seam failure ($1–5M). Speed control, temperature control, and destructive testing are the most cost-effective tools available for ensuring seam quality and long-term containment integrity.
📚 Related Technical Guides
HDPE Geomembrane Welding: A CQA Engineer's Field Manual for Speed and Temperature ControlDestructive Testing of HDPE Seams: Peel and Shear Strength Acceptance CriteriaClimate Effects on Geomembrane Welding: Temperature, Wind, and Solar Radiation ManagementExtrusion Welding Techniques: Speed, Preheat, and Quality ControlHDPE Geomembrane Failure Investigation: Welding-Related Root Cause Analysis
